Can ADHD symptoms be alleviated by supplementing with the amino acid tyrosine?
This post is a continuation from our introductory one on the effectiveness of tyrosine as an ADHD supplementation strategy.
(Blogger's note: if you do not have the time or the patience to wade through all of this information, I have provided a 7-point summary at the bottom of the page, which goes over the major points of this blog posting. If you do have the time, however, there is a lot of material and valuable research in the posting below surrounding the complex metabolic processes surrounding just one step of the tyrosine supplementation pathway for ADHD treatment).
The theory behind using the amino acid tyrosine to treat ADHD symptoms stems from the fact that tyrosine is a chemical precursor to important neurotransmitters (chemical signaling agents in the nervous system) dopamine and norepinephrine. Dopamine and norephinephrine belong to a class of signaling agents called catecholamines. Numerous studies have shown that imbalances of both of these catecholamine agents exist in most ADHD cases, and the imbalances are often on the low end (i.e. lower levels of dopamine and norepinephrine are found in several critical regions of an ADHD brain when compared to a "normal" brain).
Of course, this is a vast oversimplification of the whole process (which is much more complex), but the basic idea is that we "feed" the brain with higher levels of tyrosine and it is then able to create more of these two neurotransmitters. This idea, of giving the body higher amounts of starting material to use to convert into higher levels of the specific chemicals we want to produce is often referred to as precursor loading.
Unfortunately, as we might imagine, the process of correcting these chemical shortages an imbalances (and solving all of our ADHD problems in the process) is much more complex than popping a few tyrosine supplements. Shown below is a diagram of most of the major chemical "steps" needed to go from tyrosine (written as "L-tyrosine" below) to the catecholamines dopamine and norepinephrine A larger version of the diagram can be found by clicking the figure (in most browsers, or at the original source of the diagram, which can be found here).
We might be asking ourselves the question: Why can't we just supplement with dopamine or norepinephrine catecholamines directly to combat these ADHD-related shortages? The answer has to do with a biochemical entity known as the blood brain barrier.
The blood brain barrier is a special biochemical barrier used to control the transport of nutrients in and out of the brain. It is largely a protective measure, meant to keep toxic chemicals, which may have worked their way into the blood, out of the highly susceptible brain region. However, this blood brain barrier can also keep out some of our desired drug targets or chemical agents, including dopamine. Thus, while tyrosine (or as we'll also see in a later post, L-DOPA) can cross this barrier, dopamine cannot. As a result, we need to start with either tyrosine or L-DOPA on the outside of the blood brain barrier, shuttle these agents into the brain, and then have the brain convert them to the desired compounds.
In today's post, we will be examining the first step of the process in more detail, the conversion of tyrosine (L-tyrosine in the diagram) to L-DOPA:In order for this process to occur efficiently, we need three major components:
OPTIMIZING FACTOR #1: AN AMPLE SUPPLY OF TYROSINE:
How much tyrosine is necessary to do the job?
Unfortunately, the conversion from tyrosine to L-DOPA is not a particularly efficient process. As a result, higher levels of starting material (tyrosine) are needed. Just to give a very rough overview on the amount of tyrosine we're dealing with here in the context of ADHD treatment, typical daily supplemental doses often fall around 500 to 1500 mg per day, although there is often room for higher doses before toxicity risks set in.
At around 10-12 grams (roughly 10 times this amount), the risk of toxicity often goes way up. Other complications include high blood pressure or skin cancer (the reasons which we'll discuss in later posts), or the use of antidepressant medications, in which recommended tyrosine supplemental levels should be significantly lower (or avoided altogether).
**While tyrosine supplements can be purchased over the counter, PLEASE consult with a physician before doing any type of supplementation. In addition to the ones listed above, there are several other confounding factors which need to be taken into consideration with regards to dosing.
OPTIMIZING FACTOR #2: ADEQUATE FUNCTION OF THE ENZYME TYROSINE HYDROXYLASE
Kinetic studies (studies which measure the speed or rate of chemical reactions) have shown that this first step, L-tyrosine to L-DOPA is the rate limiting step in the tyrosine to dopamine/norepinephrine process. In other words, the "bottleneck" in this conversion process lies within the enzymatic conversion of tyrosine to L-DOPA and involves the tyrosine hydroxylase enzyme.
In addition to the fact that this enzymatic step is the slowest step in the tyrosine to dopamine conversion pathway, the tyrosine hydroxylase enzyme has some additional challenges to overcome. One of these is inhibition by its product, L-DOPA. What does this mean?
Most enzymes or enzyme systems often have some sort of "brakes" or "control switches" too keep them from running non-stop at full speed. In other words, when the body senses that enough of the desired product is attained, it will signal for these enzymes (or other regulatory systems) to either slow down or stop, to keep things balanced and in check (think of what would happen if these feedback systems weren't in place for, say, regulating appetite and feeling full, or getting an adrenaline rush that did not subside when the perceived "threat" was over).
Tyrosine hydroxylase is one such enzyme, meaning that when large amounts of dopamine or norepinephrine are eventually produced from tyrosine, the body actually begins to shut down this enzyme-regulated conversion process. Numerous studies have shown this, as tyrosine hydroxylase is inhibited by catecholamines.
In addition, other enzymes also work on tyrosine hydroxylase and help turn it "on" or "off". As a result, bombarding the system with high amounts of tyrosine will not generate equally high levels of neurotransmitters, because this feedback system is in place (and we haven't even mentioned some of the potentially harmful effects of doing this, which will be discussed in later posts).
***Blogger's note: It is not my intention as a blogger to try to dazzle or confuse anyone by using all of this technical and scientific jargon. Rather, I simply want to share how much is really going on behind the scenes when we play with the levels of just one type of supplement, like tyrosine. Having said this, I personally feel that a lot of false hope is created by advocates of supplement treatment for ADHD, as these proponents often over-simply these complexities and exaggerate the overall efficacy of these "natural" ADHD treatments. I personally would like to see more non-medication treatments tried out for ADHD management, but it is a disservice to anyone if these non-drug treatment options for ADHD aren't addressed with a similar level of scrutiny.
Getting back to the topic at hand...
Further clouding the tyrosine hydroxylase enzyme issue is the fact that there are several different forms of this enzyme which exist across the population. The enzyme tyrosine hydroxylase is actually coded for by a gene on the 11th human chromosome, which goes by the same name, the tyrosine hydroxylase gene.
It is important to note that slightly different versions of this gene among the human population actually result in slightly different versions of the tyrosine hydroxylase enzyme. A growing body of evidence suggests that individuals with certain genetic variations of this tyrosine hydroxylase enzyme are more prone to certain psychiatric disorders. While it appears that ADHD is not as strongly connected to this gene and enzyme as other disorders (such as schizophrenia or Parkinson's), it is important to note that ADHD does share some degree of biochemical overlap with some of the disorders mentioned.
It is important to note that this tyrosine hydroxylase enzyme does not act in isolation. As mentioned in the previous post, many enzymes require special "helping" agents called co-factors, which are needed to help stabilize the enzyme or system of enzymes and influence their chemical functionality.
Many vitamins and minerals serve as co-factors for various enzymes. In the case of tyrosine hydroxylase, a major necessary nutrient co-factor is iron. As we will see later, iron has all sorts of implications with regards to the dopamine synthesis pathway. This has effects on both ADHD, as well as common comorbid (co-occurring) disorders to ADHD, including sleep disorders such as Restless Legs Syndrome. In other words, it is imperative that adequate dietary intake of iron in necessary to provide the body with enough of this vital nutrient to allow enzymes such as tyrosine hydroxylase function properly.
The tyrosine hydroxylase enzyme is bound to iron. You may remember from high school or college chemistry classes that iron typically exists in two major form, the ferrous form (a "+2" positive charge) or a ferric form (a "+3" positive charge). It turns out that these two forms of iron actually exhibit major effects on the function of this tyrosine hydroxylase enzyme.
Blogger's note: The following explanation will contain a fair amount of chemistry jargon. If you have any sort of science background, you might find it interesting, if not, please skim the next few paragraphs, and we'll meet up at the bottom where I summarize these findings and applications of this info:
As mentioned above, ferrous iron is the less positively charged (or, in chemical terms, less "oxidized") form of iron, while ferric is the more positively charged or more oxidized version of iron. Both of these forms can be embedded in the tyrosine hydroxylase enzyme. It turns out, however, that it is the less-oxidized ferrous form of the iron (+2) that is required for the enzyme to convert tyrosine to L-DOPA.
On the flipside, the more oxidized ferric form of the iron (+3 charge) is actually the form of the enzyme which plays a major role in shutting down the enzyme's production by catecholamines, as in the process of feedback inhibition mentioned above.
Overgeneralizing and oversimplifying a bit here, it is advantageous for our system to keep this iron in the tyrosine hydroxylase state at the less-oxidized ferrous form if we want to keep the enzyme running (again, this is a gross oversimplification, but the general idea holds).
If you've been reading this blog for awhile, you may have come across a post a few weeks ago entitled 10 Ways Vitamin C helps treat ADHD symptoms. In this posting, we discussed some of the interactions between vitamin C and iron, and how the vitamin can not only aid in the absorption of iron (thus helping to boost iron levels necessary for proper enzyme function) but also to act as an antioxidant on the iron.
Branching off of this idea, maintaining the necessary antioxidant pools via vitamin C or other antioxidants (which will be discussed shortly), we can help keep the iron in the tyrosine hydroxylase enzyme in the reduced ferrous state and aid in the tyrosine to dopamine conversion pathway. Some earlier mammalian studies have found that activity of the tyrosine hydroxylase enzyme is compromised in a state of severe vitamin C deficiency (scurvy), with the probable culprit being the inability to maintain the reduced (+2) ferrous state. In other words, vitamin C can influence ferrous iron levels, which then influences the tyrosine hydroxylase enzyme.
OPTIMIZING FACTOR #3: THE NEED FOR TETRAHYDROBIOPTERIN (and cofactors necessary for the regeneration of this tetrahydrobiopterin)
We have seen that vitamin C can help stabilize the tyrosine hydroxylase enzyme. However, the main factor in regular tyrosine to dopamine conversion stems from a compound known as tetrahydrobiopterin, which is often abbreviated as BH4. Tetrahydrobiopterin (along with molecular oxygen) is a major cofactor of the tyrosine hydroxylase enzyme, and responsible for the addition of the hydroxyl (-OH) group to the tyrosine molecule to produce L-DOPA.
This compound is manufactured in the human body, so (except in the case of rare genetic or metabolic disorders) supplementation with tetrahydrobiopterin or its chemical precursors is not necessary. However, its synthesis (from its own series of enzymes) is dependent on adequate levels of nutrient cofactors including magnesium and zinc. Prolonged deficiencies in either or both of these minerals can therefore potentially inhibit the synthesis of tetrahydrobiopterin, and, indirectly, the tyrosine to dopamine conversion process. Please note that we have discussed both magnesium and zinc in great detail with regards to the roles they play in the onset and treatment of ADHD.
In addition to the indirect relationship between tetrahydrobiopterin and ADHD due to the impact on dopamine synthesis, tetrahydrobiopterin is important in numerous other functions as well. For example, low levels of tetrahydrobiopterin in the body have been associated with hypertension and other types of cardiovascular dysfunction.
If tetrahydrobiopterin (BH4) is the predominant compound for the tyrosine hydroxylase enzyme function, is vitamin C still potentially useful in the process?
While BH4 is a more powerful regulator of the tyrosine hydroxylase enzyme in the tyrosine to L-DOPA ADHD treatment pathway, there is some evidence that vitamin C can "help the helper". A much older study, done way back in the 1970's suggests the benefits of vitamin C on the synthesis of catecholamines like dopamine and norepinephrine. The reason given in this article is the role of vitamin C in recycling or regenerating functional forms of the tetrahydrobiopterin compound.
The whole concept of vitamin C recycling other nutrients is not new to this blog and its discussions. We have mentioned how vitamin C can "recycle" other antioxidants such as vitamin E, and how this can have an indirect impact on nutritional treatment strategies for ADHD.
To summarize the key points and suggestions which should be taken away from this the blog post:
